DPC100 Intelligent Pressure Calibrators is a single range, full scale pressure measurement, high accuracy DC current, voltage measurement and the 24VDC power output function instrument. Can be used to verify the ordinary (precision) pressure gauge, pressure transmitter, pressure regulating valves, pressure switches and pressure of real-time measurement,
DPC100 Intelligent Pressure Calibrators is a single range, full scale pressure measurement, high accuracy DC current, voltage measurement and the 24VDC power output function instrument. Can be used to verify the ordinary (precision) pressure gauge, pressure transmitter, pressure regulating valves, pressure switches and pressure of real-time measurement,
FEATURES
· Pressure measurement
· Accuracy: 0.025%FS,0.05%FS
APPLICATIONS
SPECIFICATIONS
Accuracy
Gauge types
Conventional Pressure Range Selection
|
P/N |
Pressure Range (bar) |
Accuracy |
Accuracy |
Accuracy |
|
DPC100-1 |
(-1~0)bar |
0.02, G |
0.05, G |
-- |
|
DPC100-2 |
(0~0.16) bar |
0.02, G |
0.05, G |
|
|
DPC100-3 |
(0~0.25) bar |
0.02, G |
0.05, G |
|
|
DPC100-4 |
(0~0.4)bar |
0.02, G |
0.05, G |
0.1A |
|
DPC100-5 |
(0~0.6) bar |
0.02, G |
0.05, G |
|
|
DPC100-6 |
(0~1)bar |
0.02, G |
0.05, G |
|
|
DPC100-7 |
(0~1.6)bar |
0.02, G |
0.05, G |
|
|
DPC100-8 |
(0~2.5) bar |
0.02, G |
0.05, G |
|
|
DPC100-9 |
(0~4) bar |
0.02, G |
0.05, G |
|
|
DPC100-10 |
(0~6) bar |
0.02, G |
0.05, G |
|
|
DPC100-11 |
(0~10) bar |
0.02, SG |
0.05, SG |
|
|
DPC100-12 |
(0~16) bar |
0.02, SG |
0.05, SG |
|
|
DPC100-13 |
(0~25) bar |
0.02, SG |
0.05, SG |
|
|
DPC100-14 |
(0~40)bar |
0.02, SG |
0.05, SG |
|
|
DPC100-15 |
(0~60)bar |
0.02, SG |
0.05, SG |
|
|
DPC100-16 |
(0~100)bar |
0.02, SG |
0.05, SG |
|
|
DPC100-17 |
(0~160 )bar |
0.02, SG |
0.05, SG |
|
|
DPC100-18 |
(0~250)bar |
0.02, SG |
0.05, SG |
|
|
DPC100-19 |
(0~400) bar |
0.02, SG |
0.05, SG |
|
|
DPC100-20 |
(0~600) bar |
0.02, SG |
0.05, SG |
|
|
DPC100-21 |
(0~700) bar |
0.02, SG |
0.05, SG |
|
|
DPC100-22 |
(0~1000) bar |
-- |
-- |
0.1,SG |
|
DPC100-23 |
(0~1600) bar |
-- |
-- |
0.1,SG |
|
DPC100-24 |
(0~2500) bar |
-- |
-- |
0.1,SG |
| P/N | Pressure Range (bar) | Accuracy | Accuracy | Accuracy |
|---|---|---|---|---|
| DPC100-1 | (-1~0)bar | 0.02, G | 0.05, G | -- |
| DPC100-2 | (0~0.16) bar | 0.02, G | 0.05, G | |
| DPC100-3 | (0~0.25) bar | 0.02, G | 0.05, G | |
| DPC100-4 | (0~0.4)bar | 0.02, G | 0.05, G | 0.1A |
| DPC100-5 | (0~0.6) bar | 0.02, G | 0.05, G | |
| DPC100-6 | (0~1)bar | 0.02, G | 0.05, G | |
| DPC100-7 | (0~1.6)bar | 0.02, G | 0.05, G | |
| DPC100-8 | (0~2.5) bar | 0.02, G | 0.05, G | |
| DPC100-9 | (0~4) bar | 0.02, G | 0.05, G | |
| DPC100-10 | (0~6) bar | 0.02, G | 0.05, G | |
| DPC100-11 | (0~10) bar | 0.02, SG | 0.05, SG | |
| DPC100-12 | (0~16) bar | 0.02, SG | 0.05, SG | |
| DPC100-13 | (0~25) bar | 0.02, SG | 0.05, SG | |
| DPC100-14 | (0~40)bar | 0.02, SG | 0.05, SG | |
| DPC100-15 | (0~60)bar | 0.02, SG | 0.05, SG | |
| DPC100-16 | (0~100)bar | 0.02, SG | 0.05, SG | |
| DPC100-17 | (0~160 )bar | 0.02, SG | 0.05, SG | |
| DPC100-18 | (0~250)bar | 0.02, SG | 0.05, SG | |
| DPC100-19 | (0~400) bar | 0.02, SG | 0.05, SG | |
| DPC100-20 | (0~600) bar | 0.02, SG | 0.05, SG | |
| DPC100-21 | (0~700) bar | 0.02, SG | 0.05, SG | |
| DPC100-22 | (0~1000) bar | -- | -- | 0.1,SG |
| DPC100-23 | (0~1600) bar | -- | -- | 0.1,SG |
| DPC100-24 | (0~2500) bar | -- | -- | 0.1,SG |
