KDS801 Dry Block Calibrator
1 Product features
Through reliable high precision temperature control circuit and high precision sensor, the precision is higher than that of other domestic manufacturers, and the technology has reached international standards. The first worldwide touching operation, simple and fast to use.
2 Main features:
l Small size, light weight, easy to carry;
l Various types of insertion tube, can meet the different size, quantity of sensor testing and calibration. And can be customized according to the special needs of users;
l Horizontal temperature and vertical temperature field;
l Check the depth of insertion with the industry leader;
l 5.7 inch TFTLCD touch screen, 16 bit true color RGB display, full touch operation, intuitive use;
l Fast cooling, easy to set, good temperature stability;
l Hot and fast replacement;
l With load short circuit, load switch, sensor protection and other functions.
3 General technical specifications
l lLanguage: English;
l lCommunication interface: USB Device (optional).
l lThe ambient temperature range: 0~50℃（32-122℉）;
l lAmbient humidity range: 0%-90% (non condensing);
|
|
KDS800-150A KDS801-150A |
KDS801-150B |
KDS800-650 KDS801-650 |
KDS800-1200 KDS801-1200 |
|
temperature range |
-20℃~150℃ |
-30℃~150℃ |
50℃~650℃ |
300℃~1200℃ |
|
heating rate |
30~100:20min 30~150:40min |
30~100:20min 30~150:40min |
30~300:7min 30-400:12min 30~650:25min |
30~1200:75min |
|
Display accuracy |
≤±0.1℃ |
≤±0.1℃ |
Below 400℃：≤±0.35℃ 400-650℃：≤±0.5℃ |
≤±1.2℃ |
|
Insertion depth |
160mm |
150mm |
135mm |
|
|
Average heat block diameter |
36mm |
32mm |
32mm |
39mm |
|
Temperature field stability |
≤±0.02℃ |
≤±0.02℃ |
≤±0.05℃ |
≤±0.2℃ |
|
Horizontal temperature field |
≤±0.05℃ |
≤±0.05℃ |
≤±0.05℃ |
≤±0.25℃ |
|
Vertical temperature field |
The deviation in the range of 50mm calculated from the bottom of the hole of the soaking block is 1 degree |
|||
|
Temperature unit |
℃ or ℉ |
|||
|
Temp Accuracy |
0.1% |
|||
|
Display resolution |
0.01℃ |
0.01℃ |
0.01℃ |
0.01℃ |
|
maximum power |
Negative temperature type: 500W, medium temperature type: 800W, high temperature type: 3000W |
|||
|
weight(Net weight) |
Negative temperature type: 13kg, medium temperature type: 11kg, high temperature type: 11kg |
|||
|
weight (Containing packaging) |
Negative temperature type: 23kg, medium temperature type: 18kg, high temperature type:20kg Packaging includes aluminium box and transport wooden box |
|||
|
Outline size |
Negative temperature type and high temperature type: 310*190*340mm, medium temperature type: 250*150*310mm |
|||
|
Use environment |
Ambient temperature 0-50℃, relative humidity less than 95% (no condensation) |
|||
|
Power supply |
220VAC ± 10%, 45 ~ 60Hz, optional 110VAC ± 10%. |
|||
|
Selection function |
Verification Data Recording and Exporting (KDS801 only optional), up to 250 sensors, 2500 records,USB Device Communication Interface |
|||
1. Other temperature ranges should be specified when ordering.
2. The negative temperature type of -20℃~150℃ has 4 holes,are φ6/ 8/ 10/ 12 mm .
3. The negative temperature type of -30 ~150 has 4 holes,are 6/ 8/ 12 mm.
4. The medium temperature type of has 2 kinds (2 choices 1 at the time of ordering), one is 3 holes of 8/ 10/ 12mm, the other is 4 holes of 6mm*2, 8mm*2.The high temperature
5. Type of 300 ~1200 has 4 holes, are 6/ 8/ 10/ 12mm.
6. Special specification aperture can be customized and should be specified when ordering.
| model | KDS800-150A KDS801-150A | KDS801-150B | KDS800-650 KDS801-650 | KDS800-1200 KDS801-1200 |
|---|---|---|---|---|
| temperature range | -20 ℃ ~150 ℃ | -30 ℃ ~150 ℃ | 50 ℃ ~650 ℃ | 300 ℃ ~1200 ℃ |
| heating rate | 30~100:20min 30~150:40min | 30~100:20min 30~150:40min | 30~300:7min 30-400:12min 30~650:25min | 30~1200:75min |
| Display accuracy | ≤±0.1 ℃ | ≤±0.1 ℃ | Below 400 ℃： ≤±0.35 ℃ 400-650 ℃： ≤±0.5 ℃ | ≤±1.2 ℃ |
| Insertion depth | 160mm | 150mm | 135mm | |
| Average heat block diameter | 36mm | 32mm | 32mm | 39mm |
| Temperature field stability | ≤±0.02 ℃ | ≤±0.02 ℃ | ≤±0.05 ℃ | ≤±0.2 ℃ |
| Horizontal temperature field | ≤±0.05 ℃ | ≤±0.05 ℃ | ≤±0.05 ℃ | ≤±0.25 ℃ |
| Vertical temperature field | The deviation in the range of 50mm calculated from the bottom of the hole of the soaking block is 1 degree | |||
| Temperature unit | ℃ or ℉ | |||
| Temp Accuracy | 0.1% | |||
| Display resolution | 0.01 ℃ | 0.01 ℃ | 0.01 ℃ | 0.01 ℃ |
| maximum power | Negative temperature type: 500W, medium temperature type: 800W, high temperature type: 3000W | |||
| weight(Net weight) | Negative temperature type: 13kg, medium temperature type: 11kg, high temperature type: 11kg | |||
| weight (Containing packaging) | Negative temperature type: 23kg, medium temperature type: 18kg, high temperature type:20kg Packaging includes aluminium box and transport wooden box | |||
| Outline size | Negative temperature type and high temperature type: 310*190*340mm, medium temperature type: 250*150*310mm | |||
| Use environment | Ambient temperature 0-50 ℃ , relative humidity less than 95% (no condensation) | |||
| Power supply | 220VAC ± 10%, 45 ~ 60Hz, optional 110VAC ± 10%. | |||
| Selection function | Verification Data Recording and Exporting (KDS801 only optional), up to 250 sensors, 2500 records,USB Device Communication Interface |
